Passive three-way splitter for running multiple antennas, or combining receive antennas, from a single feed line.

bare pcb

10.00 €

10.00 € tax excl.

Last items in stock

Details

Features

Reviews

Tab Title

This 3-way small splitter is a very useful device. It can provide equal voltages, equal current, or equal power to matched or unmatched loads. Like all passive splitters and combiners, this device is less than ideal. Isolation is maximum only when at least one port are properly terminated. In this case isolation between the three splitted/combinated ports is maximum when the main port is properly terminated. This HW is designed only for RX line. Both impedances 50 or 75 Ohm can be selected by the jumper.

Using

Antenna combiner - 3 el broad side array
RX signal divider
10 MHz signal splitter
One antenna to three RX

Main functions

Broadband: 0.1 MHz to 60 MHz
3-way Splitter or Combiner
Low loss
50 / 75 Ohm impedance - easy jumper switch
Quality SMA connectors
Aluminium enclosure: W x H x L = 58 x 24 x 50
4pcs self adhesive feet pads included
ASSEMBLED and TESTED VERSION

Parameters

Impedance 50 or 75 Ohm
Insertion loss: around 1 dB
Split 4.8 dB, together with IL around 5.8 dB
Isolation more than 18 dB for middle port and more than 23 dB for 1st and 3rd port
SWR on splitted ports better than 1 : 1.15 on HF, resp. 1 : 1.25 on 6m
SWR on main port around 1 : 1.3 on HF, resp. 1 : 1.4 on 6m

Available as

ASSEMBLED with BOX: ready to use
ASSEMBLED: ready to use - ASSEMBLED VERSION
KIT: all parts + PCB - KIT VERSION
PCB: only PCB
